Specifications

• Dimensions

  add remove
  • Length:
    87.2 in
  • Ground clearance:
    5.7 in
  • Rake (steering head):
    32
  • Trail:
    4.5 in
  • Wheelbase:
    1,520.0 in
  • Tires, front specifications:
    100/80-17
  • Tires, rear specifications:
    140/75 R15
  • Fuel Capacity:
    3.5 gal
  • Oil capacity:
    3.3 qt.
  • Weight, as shipped:
    492 lbs
  • Weight, in running order:
    514 lb. (233 kg) lb
• Engine

  add remove
  • Engine:
    Liquid-cooled, Revolution X™ V-Twin
  • Bore:
    2.7 in
  • Stroke:
    2.6 in
  • Displacement:
    30.15 in³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    Black two into one
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    29.5 ft-lb
  • Lean angle, right (deg.):
    28.5
  • Lean angle, left (deg.):
    28.5
  • Fuel economy:
    0.00 mpg
• Powertrain

  add remove
  • Primary drive:
    Gear, 36/68 ratio
  • Gear ratios (overall) 1st:
    14.272
  • Gear ratios (overall) 2nd:
    10.074
  • Gear ratios (overall) 3rd:
    7.446
  • Gear ratios (overall) 4th:
    6.006
  • Gear ratios (overall) 5th:
    5.037
  • Gear Ratios (overall) 6th:
    4.533
• Chassis

  add remove
  • Wheels, front type:
    Black, 7-spoke Cast Aluminum
  • Wheels, rear type:
    Black, 7-spoke Cast Aluminum
  • Brakes, caliper type:
    2-piston floated front and rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning
  • Gauges:
    3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap
